SKU:
KNF N 036.0
PLEASE LODGE AN ENQUIRY FOR THE CURRENT PRICE
Description
- Flow Rate (max.): 60 l/min
- Pressure (max.): 1.5 bar (rel.)
- Vacuum (max.): 200 mbar (abs.)
KNF diaphragm gas pumps transfer or compress gases and vapours and generate vacuum without contaminating the media. They are available with options for application requirements related to size, motor, control, voltage, chemical resistance, safety, vibration, noise and temperature resistance. All pump types offer oil-free operation.
Technical Details
| Flow Rate (max.) | 60 l/min |
| Pressure (max.) | 1.5 bar (rel.) |
| Ultimate Vacuum (max.) | 200 mbar (abs.) |
| Valve Material Options | PTFE |
| Diaphragm Material Options | PTFE |
| Pump Head Material Options | Stainless steel, Aluminium |
| Motor Type Options | AC |
Features
Benefits
- Excellent reliability
- Contamination free transfer
- Highly resistant to aggressive media
Special Features
- Diaphragm pump
- Hot gases
- High IP class (>44)
Applications
- Analytical instruments
- Automotive
- Chemical industry
- Gas analytics
- Emission monitoring
Downloads
3D CAD Model N 036.0.16Catalogues
